Methanol Fuel Fired Thermal Oil Heaters adopt three pass structure , fire tube design. Methanol Fuel Fired Thermal Oil Heaters adopt special Methanol Fuel burner, which adopt ratio adjustment design, automatic control flame and full automatic working technology. This methanol fired thermal oil heater has the feature of compact structure, safety working, easy installation and high thermal efficiency.
Table of Contents
Parameter Table of YYW Diesel Oil Fired Thermal Oil Boilers
| Item | YYW60 | YYW120 | YYW180 | YYW240 | YYW350 | YYW470 | YYW700 | YYW950 | YYW1200 | YYW1400 | |
| Power | 104kcal/h | 5 | 10 | 15 | 20 | 30 | 40 | 60 | 80 | 100 | 120 |
| Capacity | MW | 0.06 | 0.12 | 0.18 | 0.24 | 0.35 | 0.47 | 0.7 | 0.95 | 1.2 | 1.4 |
| Theraml Efficiency | % | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 83 | 84 |
| Pressure | Mpa | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 |
| Max. Temp. | °C | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 | 320 |
| Circulation Oil | m3/h | 10 | 12.5 | 20 | 20 | 40 | 60 | 80 | 100 | 100 | 100 |
| Oil Pipe | DN | 50 | 50 | 65 | 65 | 80 | 100 | 100 | 125 | 125 | 125 |
| System Power | KW | 5 | 5 | 5 | 8 | 10 | 15 | 20 | 45 | 55 | 55 |
| Fuel | diesel.oil.gas, Methanol Fuel, etc | ||||||||||
Thermal Oil Boiler Production Equipment
Factory Visit
Company Profile
Romiter Group Limited are committed to manufacturing and exporting complete enery saving heating equipment, including thermal oil boiler (Thermal fluid heat transfer product), thermal oil steam generator, cryogenic storage Dewar. After many years reach & development, Romiter Group can provide coal fired thermal oil boiler, gas fired thermal oil boiler, diesel fired thermal oil boiler, electric heating thermal oil boiler, coal fired molten salt heater, waste wood fired thermal oil heater, wood block fired thermal oil heater, thermal oil heating steam generator, gas or oil fired molten salt heater and all type liquid gas vacuum cryogenic storage Dewar.
Great Service, High Quality, Competitive prices, and Timely delivery is our business philosophy.
